EVIS EXERA III Video Bronchoscope BF-Q190BF-Q190
The BF-Q190 slim bronchoscope is ideal for diagnostic bronchoscopy and treatment in the deeper bronchi. The insertion tube measures only 4.9 mm and the distal end is just 4.8 mm, yet it still has a generous 2.0 mm channel. As a standard bronchoscope, the BF-Q190 offers great functionality and exceptional image quality, with high resolution across the 120° field of view and greatly improved NBI capability. The rotatable insertion tube and increased upward angulation improve maneuverability, while features like the waterproof one-touch connector, improve endoscopy suite management.
Stunning high resolution imaging in a slim scope
Advancing visualisation: The BF-Q190 offers high resolution imaging in white light and NBI modes. The system-incorporated pre-freeze function provides sharp still image capture within a fraction of a second.
Insertion tube rotation function and 210° angulation
Advancing maneuverability: The slim insertion tube (4.9 mm diameter, 4.8 mm distal end) along with its unique rotation function and the increased upward angulation of 210° provide further insertion support, allow precise targeting during sampling and offer additional degrees of freedom to perform the procedure in a more comfortable body position.
Fully waterproof endoscope and one-touch connector
The design of the new waterproof connector allows full submersion without a water-resistant cap and eliminates the associated risk of an expensive repair due to accidental immersion of the endoscope. The one-touch connector links the endoscope to the endoscopy system in a single movement and thus minimises the effort required for set-up prior to and in between cases.
